References and Tests - InfiniSpring

19.04.2024

InfiniSpring® Acoustic Direct Hanger and Low Height Acoustic Ceilings

InfiniSpring® is a thin spring and this offers possibilities for space savings in vibration and noise isolation applications. To minimize the space above the visible soundproofed ceiling we developed a new type of acoustic direct hanger solution, which enables extremely low height soundproofed suspended ceilings. In buildings lower space can minimize the building costs and lower height rooms can be equipped with soundproof suspended ceilings.

Other

18.12.2023

How to calculate suspended ceiling?

A 7m x 10 m size ceiling utilizes two layers of plasterboard with the following area densities: 1 x 10 kg/m2 and 1 x 15 kg/m2. How are acoustic hanger support distances and acoustic hanger amounts defined?

Other

11.12.2023

Design Services

If you want to innovate new products, challenge existing designs, optimize your products or improve your simulation procedures, we are happy to offer our support.

Other

07.12.2023

How InfiniSpring® Acoustic Products Improve Soundproofing?

We hear sounds from about 20 Hz to 20 kHz. This range is also a commonly referenced audio frequency range. InfiniSpring® Acoustic Products attenuate noise from around 14 Hz upwards and improve soundproofing in the whole audio frequency range.

24.11.2023

Standardized InfiniSpring® Acoustic Wall Ties Introduced

We wanted to extend our acoustic product offering and developed acoustic products for the walls. New acoustic wall ties utilize standardized spring plate and connection parts. Acoustic wall ties decouple walls and prevent airborne noise passing into the rooms next door.

03.11.2023

Standardized InfiniSpring® Acoustic Hangers Introduced

InfiniSpring® acoustic hangers utilize a standardized laser cut spring plate, which can be equipped with different types of upper connections based on the needs. Acoustic hangers are used to soundproof ceilings.

06.10.2023

New Acoustic Spring Hanger from the InfiniSpring® Company

We have a new InfiniSpring® acoustic hanger now available. High performance acoustic hangers are used in suspended ceilings to isolate the transmission of impact and airborne noise from one room to another.

01.09.2023

Wooden support bracket for air conditioner / air heat pump

We have made new type of wooden support bracket for the air heat pump outdoor units. 3 mm thick InfiniSpring® function perfectly for the outdoor unit vibration and noise isolation. The support bracket is made from impregnated wood and whole installation is made using 5 mm screws.

23.03.2022

New Vibration Isolation Platform from the InfiniSpring® Company

InfiniSpring®-vibration isolation platform is a high performing general-purpose platform. It is placed between the vibration source and the floor. Platform is made from sheet metal, which allows easy customization and flexible positioning of any fasteners needed. Platform suits also for laboratory devices when they are protected from harmful vibration.

11.03.2022

New Spring Mount Family from the InfiniSpring® Company

New product family InfiniSpring®-spring mounts is now available. Different size rubber mounts and coil spring mounts are used traditionally in numerous applications today and we wanted InfiniSpring®-springs to be used in these same applications. New spring mount design utilizes two InfiniSpring®-springs and single spring mounts can be loaded from 15 kg up to 600 kg.

03.01.2022

Concrete Inertia Base with Integrated Springs

By utilizing InfiniSpring® a concrete inertia base can be manufactured as a pure sheet metal component. The concrete inertia base reduces equipment vibration, decreases motions during start and shut-down, prevents movement between driving unit and non-driving unit and functions as a structure borne noise isolator. InfiniSpring® concrete inertia base is efficient and very straight forward way for installing mechanical equipment resiliently.

26.10.2020

Vibratec Oy Shaker Table with Integrated Springs

Vibratec Oy is an expert company focused on vibrating technics. Vibratec Oy designs and manufactures shaker tables as one of their products. Labrys Oy introduced the new InfiniSpring® design to Vibratec Oy CEO Aimo Immonen and Design Engineer Markku Immonen. Both Aimo and Markku were inspired by InfiniSpring® and saw great potential for use in their product line. This led to a new shaker table development project with the integration of InfiniSpring®.

26.10.2020

Koja Oy Fan Unit with Integrated Springs

Koja Oy is a family-owned company offering customers intelligent and energy efficient HVAC systems, air handling systems and industrial fan solutions. Labrys Oy presented the new InfiniSpring® solution to Koja Oy R&D Management. Antti Häyrynen from Koja Oy R&D Management saw the potential in the InfiniSpring® integration and a new fan unit design was targeted to utilize InfiniSpring®-springs.

Test

24.09.2020

How to select InfiniSpring® for a fan?

The test case fan is equipped with a 2.2 kW electric motor, which is controlled via variable-frequency drive. The motor nominal speed is 1440 rpm. The fan is used in air handling units and typically equipped with rubber elements. In this article InfiniSpring®-springs are dimensioned below the fan.

Test

14.09.2020

Which frequencies are harmful for fan installations and what is fan’s minimum operating frequency?

Test case fan is equipped with 3HS20 InfiniSpring®-springs and with a 2.2 kW electric motor, which is controlled via variable-frequency drive. Motor nominal speed is 1440 rpm. This article focuses on testing the fan with big unbalance to see which rigid body modes are harmful for the fan installation.

Test

08.09.2020

How safe is the spring selection based only on the weight data of a fan?

The test case fan is equipped with 3HS20 InfiniSpring®-springs and a 2.2 kW electric motor, which is controlled via variable-frequency drive. The motor nominal speed is 1440 rpm. The fan is used in air handling units and typically equipped with rubber elements. This article focuses on validating InfiniSpring®-spring selection based on the fan weight data.
